Industrial DC/DC power supply - Input voltage DC 10 - 20V - Output voltage DC 52V - Maximum output 5A / 240W - Lightweight and compact - IP68
📋 SPECIFICATIONS:
• Type: Industrial DC/DC power supply
• Nominal input voltage: DC 12V
• Input voltage range: DC 10-20V
• Efficiency: 95.7%
• Output voltage: DC 52V
• Output current: 5A
• Maximum output power: 240W
• Number of outputs: 1
• Voltage regulation: <1%
• Load regulation: <2%
• Ripple at full load: <170mV
• No-load current: <40mA
• Operating temperature: -40 - 80ºC
• Protections: Overvoltage, overcurrent, and overtemperature
• Dimensions: 100 x 80 x 39mm
• Weight: 550g
• Protection rating: IP68
• Cooling: Natural convection
• Certifications: CE, RoHS
• Operating temperature range: -40 - 55ºC
• Storage temperature range: -55 - 100ºC
📦 INCLUDED:
• 1x DC/DC converter
| Type | Industrial DC/DC power supply |
|---|---|
| Nominal input voltage | DC 12V |
| Input voltage range | DC 10-20V |
| Efficiency | 95.7% |
| Output voltage | DC 52V |
| Output current | 5A |
| Maximum output power | 240W |
| Number of outputs | 1 |
| Voltage regulation | <1% |
| Load regulation | <2% |
| Ripple at full load | <170mV |
| No-load current | <40mA |
| Working temperature | -40 - 80ºC |
| Protections | Overvoltage, overcurrent and overtemperature |
| Dimensions | 100 x 80 x 39mm |
| Weight | 550g |
| Protection rating | IP68 |
| Cooling | Natural convection |
| Certifications | CE, RoHS |
| Operating temperature range | -40 - 55ºC |
| Storage temperature range | -55 - 100ºC |
