Infrared beam detector
Regular price
€41,50
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Infrared barrier detector - Wired | 2 beams - Max. detection distance 60 / 180 m - Highly configurable - Tamper | Relay output | LED Display - Power supply 12~24VDC/VAC
- Dual-beam infrared barrier for outdoors
- Wired
- Maximum transmitter/receiver detection 180 m (indoors) and 60 m (outdoors)
- Dual adjustable lens
- H: ±90º / V: ±10º
- DIP Switch for programming
- 4 operating frequencies
- LED display for easy installation
- Power supply 12~24 VDC/VAC
Technical datasheet
| Detection range | 180m indoor / 60m outdoor |
| Number of beams | 2 |
| Detection method | Simultaneous interruption of the 2 beams |
| Interruption time | 50ms, 100ms, 300ms, 700ms (selectable) |
| Frequency channels | 4 different channels via DIP Switch |
| Alarm outputs | 1 relay NO/NC (max. 30VDC/VAC, 1A), Tamper NC |
| Adjustment angle | Horizontal 180°(±90°), Vertical 20°(±10°) |
| Adjustment method | Via LCD Display between 0-99 |
| Operating temperature | 25ºC ~ +55ºC |
| Protection level | IP65 |
| Power supply | 12~24 VDC/VAC, 75 mA max. |
| Dimensions | 211.5 (W) x 79.9 (H) x 74.7 (D) mm |
Technical features
- Infrared barrier Wired | 2 beams
- Max. detection distance 60 / 180 m
- Tamper | Relay output | LED Display
- Power supply 12~24VDC/VAC
| Detection range | 180m indoor / 60m outdoor |
|---|---|
| Number of beams | 2 |
| Detection method | Simultaneous interruption of 2 beams |
| Interruption time | 50ms, 100ms, 300ms, 700ms (selectable) |
| Frequency channels | 4 different channels via DIP Switch |
| Alarm outputs | 1 relay NO/NC (max. 30VDC/VAC, 1A), Tamper NC |
| Adjustment angle | Horizontal 180°(±90°), Vertical 20°(±10°) |
| Adjustment method | Via LCD Display between 0-99 |
| Operating temperature | -25ºC ~ +55ºC |
| Protection rating | IP65 |
| Power supply | 12~24 VDC/VAC, 75 mA max. |
| Dimensions | 211.5 (W) x 79.9 (H) x 74.7 (D) mm |
- User manual Link
