Elettricity

Video Balun for HDTVI / HDCVI / AHD / CVBS

SKU: BA614P-HAC
(0)
In stock
Usually shipped within 24 hours
€29,97 Final price
-6% €32,00 €29,97 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Video Balun for HDTVI / HDCVI / AHD / CVBS - 4 passive channels - Includes 4 BA612P-HAC - BNC and RJ45 connection - Distance: 180 ~ 440 m

📋 SPECIFICATIONS:
• Tx Input / Rx Output: 4 female BNC connectors for video
• Tx Output / Rx Input: 1 RJ45 connector or 4 terminal block connectors for UTP CAT5 cable
• Bandwidth: DC to 42 MHz
• Video format: NTSC, PAL, SECAM
• Impedance: BNC 75 Ω, UTP 100 Ω
• Transmission distance: HDTVI 200/200/200/200 m (720p/1080p/4 Mpx/4K), HDCVI 400/200/200/200 m (720p/1080p/4 Mpx/4K); AHD 300/200/200 m (720p/1080p/4 Mpx), CVBS 300 m
• Power supply: Passive (Not required)
• Dimensions: 25 (W) x 102 (H) x 90 (D) mm
• Weight: 200 g

📦 INCLUDED:
• 4-channel balun • Installation material • 4 BA612P-HAC baluns • Instructions
Tx Input / Rx Output 4 female BNC connectors for video
Tx Output / Rx Input 1 RJ45 connector or 4 terminal block connectors for CAT5 UTP cable
Bandwidth DC to 42 MHz
Video format NTSC, PAL, SECAM
Impedance BNC 75 Ω, UTP 100 Ω
Transmission distance HDTVI 200/200/200/200 m (720p/1080p/4 Mpx/4K), HDCVI 400/200/200/200 m (720p/1080p/4 Mpx/4K) AHD 300/200/200 m (720p/1080p/4 Mpx), CVBS 300 m
Power supply Passive (Not required)
Dimensions 25 (W) x 102 (H) x 90 (D) mm
Weight 200 g
