ATT-SCUPC-10
ATT-SCUPC-10

Note: actual colors may vary slightly from the images due to different monitor settings and lighting conditions during shooting.

Elettricity

Exact 10dB optical signal attenuation - High-density compact SC connector

SKU: ATT-SCUPC-10
(0)
In stock
Usually shipped within 24 hours
€4,95 Final price
-18% €6,00 €4,95 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Exact 10dB attenuation in the optical signal. - Compact high-density SC connector. - UPC polish that reduces reflections. - Thermal stability in critical environments. - Direct Plug and Play installation. - Universal OS2 single-mode compatibility.

📋 SPECIFICATIONS:
• Component type: Fixed optical attenuator
• Connector type: SC / UPC (male to female)
• Attenuation value: 10 dB
• Attenuation accuracy: ±0.5 dB
• Compatible fiber type: Single-mode (SMF) OS1/OS2 9/125 µm
• Operating wavelengths: 1310 nm, 1550 nm, and 1490 nm
• Return Loss: ≥ 50 dB
• Polarization Dependent Loss (PDL): ≤ 0.2 dB
• Maximum optical input power: 200 mW / +23 dBm
• Ferrule material: Zirconium oxide (ZrO2)
• Housing material: Engineering plastic (UL94V-0 polymer)
• Housing color: Blue (UPC standard)
• Operating temperature: -40 °C to +75 °C
• Storage temperature: -40 °C to +85 °C
• Operating relative humidity: 95% RH (non-condensing)
• Connection stability: > 1000 matings
• Approximate dimensions: 34 mm x 12 mm x 8 mm
• Environmental compliance: RoHS / REACH

📦 INCLUDED:
• 1x SC/UPC 10dB Fixed optical attenuator
Component type Fixed optical attenuator
Connector type SC / UPC (male to female)
Attenuation value 10 dB
Attenuation accuracy ±0.5 dB
Compatible fiber type Single-mode (SMF) OS1/OS2 9/125 µm
Operating wavelengths 1310 nm, 1550 nm, and 1490 nm
Return loss ≥ 50 dB
Polarization Dependent Loss (PDL) ≤ 0.2 dB
Maximum optical input power 200 mW / +23 dBm
Ferrule material Zirconium oxide (ZrO2)
Housing material Engineering plastic (UL94V-0 polymer)
Housing color Blue (UPC standard)
Operating temperature -40 °C to +75 °C
Storage temperature -40 °C to +85 °C
Operating relative humidity 95% RH (non-condensing)
Connection stability > 1000 matings
Approximate dimensions 34 mm x 12 mm x 8 mm
Environmental compliance RoHS / REACH
