Exact 10dB optical signal attenuation - Secure standard SC connector

SKU: ATT-SCAPC-10
(0)
In stock
Usually shipped within 24 hours
€5,08 Final price
-18% €6,20 €5,08 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Exact 10dB attenuation in the optical signal. - Secure standard SC connector. - APC angled polishing that eliminates reflections. - Thermal stability in critical environments. - Direct Plug and Play installation. - Universal OS2 single-mode compatibility.

📋 SPECIFICATIONS:
• Component type: Build-out fixed optical attenuator
• Connector type: SC / APC (male to female)
• Attenuation value: 10 dB
• Attenuation accuracy: ±0.5 dB
• Compatible fiber type: Single-mode (SMF) OS1/OS2 9/125 µm
• Operating wavelengths: 1310 nm and 1550 nm (dual window)
• Return loss: ≥ 65 dB
• Polarization Dependent Loss (PDL): ≤ 0.2 dB
• Wavelength Dependent Loss (WDL): ≤ 0.3 dB
• Maximum optical input power: 200 mW / +23 dBm
• Ferrule material: Zirconium oxide (ZrO2)
• Ferrule polishing angle: 8° (Angled Physical Contact)
• Housing material: Flame-retardant plastic polymer (UL94V-0)
• Body color: Green (APC standard)
• Operating temperature: -40 °C to +75 °C
• Storage temperature: -40 °C to +85 °C
• Operating relative humidity: 95% RH (non-condensing)
• Mechanical durability: > 1000 mating cycles
• Standards compliance: Telcordia GR-910-CORE / IEC 61754
• Environmental compliance: RoHS / REACH

📦 INCLUDED:
• 1x SC/APC 10dB fixed optical attenuator
Component type Fixed build-out optical attenuator
Connector type SC / APC (male to female)
Attenuation value 10 dB
Attenuation accuracy ±0.5 dB
Compatible fiber type Single-mode (SMF) OS1/OS2 9/125 µm
Operating wavelengths 1310 nm and 1550 nm (dual window)
Return Loss ≥ 65 dB
Polarization Dependent Loss (PDL) ≤ 0.2 dB
Wavelength Dependent Loss (WDL) ≤ 0.3 dB
Maximum optical input power 200 mW / +23 dBm
Ferrule material Zirconium dioxide (ZrO2)
Ferrule polishing angle 8° (Angled Physical Contact)
Housing material Flame-retardant plastic polymer (UL94V-0)
Body color Green (APC standard)
Operating temperature -40 °C to +75 °C
Storage temperature -40 °C to +85 °C
Operating relative humidity 95% RH (non-condensing)
Mechanical endurance > 1000 mating cycles
Standards compliance Telcordia GR-910-CORE / IEC 61754
Environmental compliance RoHS / REACH
