ADVANCED

Network interface for Advanced IP connection

SKU: ADV-MXP-554-BX
(0)
Disponibile su richiesta
Available upon request
€1.312,00 Final price
-5% €1.382,00 €1.312,00 Final price
Su richiesta · chiedi all'assistente

Articolo ordinato su richiesta: prezzo definitivo e tempi li conferma il nostro tecnico.

Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Network interface for IP connection - Access to all AD-NET network panels - E-mail notification - Compatible with Axis EN, Mx-5000 and Mx-4000

📋 SPECIFICATIONS:
• Brand: Advanced
• Certification: EN54-18
• LAN interface: 10Base-T, RJ45
• Serial interface: Isolated RS232 interface
• Fault input: Fault monitoring input for power supply
• Indicators: LEDs on the board to indicate: HEARTBEAT, NETWORK transmission, RS232 transmission/reception, activity, connectivity and LAN operation
• Protection: IP30
• Power supply: 24V (18~28V) DC
• Consumption: 70mA at 24VDC
• Operating temperature: -5ºC ~ 40ºC
• Humidity: max. 95%
• Dimensions / weight: PCB: 38.5mm (H) x 245mm (W) x 90mm (D); Enclosure: 218mm (H) x 300mm (W) x 45mm (D); 2Kg
Certification EN54-18
LAN interface 10Base-T, RJ45
Serial interface Isolated RS232 interface
Fault input Power fault monitoring input
Indicators LEDs on the board to indicate: HEARTBEAT, NETWORK transmission, RS232 transmission/reception, activity, connectivity, and LAN operation
Protection IP30
Power supply 24V (18~28V) DC
Consumption 70mA at 24VDC
Operating temperature -5ºC ~ 40ºC
Humidity max. 95%
Dimensions / weight PCB: 38.5mm (H) x 245mm (L) x 90mm (W) Enclosure: 218mm (H) x 300mm (W) x 45mm (D) 2Kg
