ADVANCED

Advanced analog module - 1 supervised input and 1 supervised output

SKU: ADV-20-VMMIC100
(0)
In stock
Usually shipped within 24 hours
€87,62 Final price
-5% €92,00 €87,62 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Advanced analogue module - 1 supervised input and 1 supervised output - Built-in short circuit isolator - Compatible with Argus Vega protocol - Conductor cable up to 2.5mm2 - EN54-17, EN54-18 certified

📋 SPECIFICATIONS:
• Brand: Advanced
• DC Voltage: Nominal 24V (15~40V)
• Average consumption: 120μA
• LED consumption (max.): 6mA@24VDC
• Supported wiring: Accepts cables up to 2.5mm2
• End-of-line resistor (REOL): 27Kohm
• Alarm resistor (Rw): 10Kohm
• Relay characteristics: 30VDC / 2A max.
• Operating temperature range: -30ºC ~ +70ºC
• Humidity (non-condensing): 95% RH
• Dimensions: 52 x 75 x 28 mm (H x W x D)
• Weight: 180g
• IP Rating: IP21C
• Certification: EN 54-17, EN54-18

📦 INCLUDED:
• Advanced module
DC voltage Nominal 24V (15~40V)
Average consumption 120μA
LED consumption (max.) 6mA@24VDC
Supported wiring Accepts cables up to 2.5mm2
End-of-line resistor (REOL) 27Kohm
Alarm resistor (Rw) 10Kohm
Relay specifications 30VDC / 2A max.
Operating temperature range -30ºC ~ +70ºC
Humidity (non-condensing) 95% RH
Dimensions 52 x 75 x 28 mm (H x W x D)
Weight 180g
IP protection IP21C
Certification EN 54-17, EN54-18
