ADVANCED

Advanced analog module - 1 conventional zone

SKU: ADV-20-VMCZ100
(0)
In stock
Usually shipped within 24 hours
€107,22 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Advanced analog module - 1 conventional zone - Built-in short-circuit isolator - Compatible with Argus Vega protocol - Conductor cable up to 2.5mm2 - EN54-17, EN54-18 certified

📋 SPECIFICATIONS:
• Brand: Advanced
• DC Voltage: Nominal 24V (15~40V)
• Average consumption: 120μA
• Standby consumption: 500μA
• Power-up time: 2 seconds
• Device end-of-line zone: Capacitor (Ceol): 4.7μF
• Conventional zone current threshold: 6 to 20mA (alarm threshold 2.5 to 15mA)
• Relay characteristics: 30VDC / 2A max.
• Operating temperature range: -30ºC ~ +70ºC
• Humidity (non-condensing): 95% RH
• Dimensions: 93 x 130 x 58 mm (H x W x D)
• Weight: 190g
• IP rating: IP54
• Certification: EN 54-17, EN54-18

📦 INCLUDED:
• Advanced module
DC Voltage Nominal 24V (15~40V)
Average consumption 120μA
Standby consumption 500μA
Switch-on time 2 seconds
Device end-of-line zone Capacitor (Ceol): 4.7μF
Conventional zone current threshold 6 to 20mA (alarm threshold 2.5 to 15mA)
Relay specifications 30VDC / 2A max.
Operating temperature range -30ºC ~ +70ºC
Humidity (non-condensing) 95% RH
Dimensions 93 x 130 x 58 mm (H x W x D)
Weight 190g
IP rating IP54
Certification EN 54-17, EN 54-18
